UL2835 Certified Cable (General Type)

Close-up of a fiber optic cable with a silver connector labeled UL2835.

Description:

  • UL2835 certified cable is a multi-conductor power and control cable designed for use in Class 2 electronic circuits where stable signal transmission and interference protection are required.

  • It offers multiple construction options, allowing customization of conductor type, insulation, shielding, and sheath materials.

  • Manufactured according to UL758, UL1581, and CSA C22.2 No.210.2 standards, the cable provides excellent flexibility, flame retardancy, and EMI shielding performance, making it suitable for both internal and external wiring of electronic devices.

Applications:

  • Internal and external wiring for Class 2 electronic circuits

  • Power and control lines for electronic devices

  • Applications requiring shielding and noise suppression

  • Commonly used in gaming consoles, mobile chargers, and small appliances

  • Can be substituted by UL21304 or UL21452 wire types

Technical Specifications:

  • Rated Voltage: 300V

  • Test Temperature: 60°C (140°F)

  • Spark Test: 2kV

  • Flame Test: UL VW-1, CSA FT1, and JQA F-Mark compliant

  • Conductor: 40 AWG and larger, available in bare copper, tinned copper, or copper foil wire

  • Insulation: Special hard, heat-resistant, flame-retardant PVC or equivalent material (color optional)

  • Core Structure: Two or more twisted pairs; Pairing, and shielding configuration available

  • Shielding: Optional tinned copper or bare copper braid/shield for EMI protection

  • Sheath: Mixed 80°C heat-resistant, flame-retardant PVC, color optional

  • Key Features: Flexible structure design, strong shielding performance, and multifunctional power/control capabilities
