KVVP Braided Shield Control Cable

Fiber optic cable with multiple thin fibers extending from a black protective sheath, labeled 'KWP'.

Description:

  • KVVP is a PVC-insulated and sheathed braided shield control cable designed for fixed installations requiring reliable signal transmission and electromagnetic interference (EMI) protection.
    It features stranded copper conductors, PVC insulation, a copper wire braid shield, and a PVC sheath, providing excellent shielding effectiveness, durability, and electrical insulation.

  • Manufactured according to GB/T 9330.2 (equivalent to IEC 60227-7: Polyvinyl chloride insulated cables for fixed wiring — Control cables) and GB/T 3956 (equivalent to IEC 60228: Conductors of insulated cables).

Applications:

  • Used for control, monitoring, measurement, and protection circuits in electrical and automation systems requiring stable signal transmission with shielding.

  • Commonly applied in electrical instruments, distribution panels, metering systems, automation, and alarm circuits.
    Suitable for indoor wiring, cable trenches, conduits, and other fixed installations that demand protection against external electromagnetic interference.

  • Ideal for measurement, testing, remote monitoring, computer networking, and control systems.

Technical Specifications:

  • Rated Voltage: 450/750V

  • Test Voltage:

    • Insulation thickness ≤ 0.6 mm: 2000V

    • Insulation thickness ≥ 0.6 mm: 2500V

    • Outer sheath test: 3000V

  • Standards:

    • GB/T 9330.2 — equivalent to IEC 60227-7

    • GB/T 3956 — equivalent to IEC 60228

  • Conductor: Class 1 or Class 2 stranded copper conductors (GB/T 3956 / IEC 60228)

  • Insulation: PVC/A-type polyvinyl chloride insulation for fixed installation

  • Color Code:

    • For cables with five or more cores: black cores with white printed numbers (1, 2, 3, …), arranged clockwise from the inner to outer layer

    • One yellow-green grounding conductor placed in the outermost layer

  • Core Structure: Interstices between conductors filled; optional isolation wrapping with PP tape or nonwoven fabric; non-adhesive insulated cores

  • Shield: Braided bare copper or tinned copper wires

  • Sheath: PVC/ST1 sheath, color black (RAL9005) or gray (RAL7001)

  • Minimum Bending Radius:

    • Fixed installation: 6 × cable diameter (D)

  • Operating Temperature Range:

    • Fixed installation: −10°C to +70°C

    • Flexible installation: −5°C to +70°C

  • Radiation Resistance:

    • 8 × 10⁷ cJ/kg

  • Flame Retardancy: Passed GB/T 18380 (IEC 60332-1) flame retardant test
