Flexible Shielded Drag Chain Cable (TRVVP)

Cross-section diagram of an electrical cable showing multiple insulated wires inside a protective outer sheath.

Product Features

  • Bending lifespan: Over 10 million cycles

  • Travel speed: Up to 3 m/s

  • Characteristics: Water- and oil-resistant, UV- and weather-resistant, cold- and abrasion-resistant, with strong mechanical durability and excellent EMC performance (anti-interference).
    Designed for continuous reciprocating motion in dynamic industrial environments.

Application:

  • Ideal for drag chain systems, logistics and control equipment, CNC machines, automation systems, robotic arms, injection molding, metal stamping, woodworking and glass machinery, heavy machinery, construction equipment, and other applications requiring shielded cables for both indoor and outdoor use.

Technical Specifications

  • Conductor: Multi-stranded, ultra-fine oxygen-free copper wire

  • Insulation: Special blended PVC insulation

  • Color Coding:

    • ≤ 0.5 mm² — colored cores: brown, black, blue, violet, pink, orange

    • ≥ 0.5 mm² — black cores with white numbering; three-core and above include yellow-green grounding wire

  • Sheath: Special PVC compound

  • Sheath Color: Black (RAL9005), Gray (RAL7001), Orange (RAL2003)

  • Rated Voltage: < 0.5 mm² — 300/300V
